IQ Hardwire PowerG

Why Choose IQ Hardwire PowerG with Smart Shield Systems

• Professional takeover design to reuse doors, windows, motions, glass breaks, and more

• Clean, code-compliant installation with labeled zones and power calculations

• Reliable PowerG performance: long-range, encrypted, frequency-hopping radio

• Ongoing support & monitoring through your IQ Panel and mobile app

Key Features

• 8 hardwired zones on-board (with expansion options on select models).

• 4 PGM outputs for siren/strobe/relay rules; PGM2 supports 2-wire smoke loop.

• Supports up to 18 conventional 2-wire smoke detectors on the dedicated loop.

• Two independent AUX power circuits (best practice: AUX1 for intrusion, AUX2 for life-safety).

• Supervised siren output (12V @ up to ~700 mA).

• Enhanced security: 128-bit AES, two-way TDMA, DEOL (double end-of-line) support, tamper (incl. back tamper), and power-supply supervision.

• Pair up to two hardwire units to one IQ Panel (model/firmware dependent).

Technical Highlights (At-a-Glance)

Converter (PG9WLSHW8)

• Zones/PGMs: 8 zones, 4 PGMs; supports 18× 2-wire smokes on PGM2

• Power: 18 VDC 2.22 A plug-in adapter; 12 V 7 Ah backup battery (charging at 13.7 V / 360 mA)

• Outputs: Siren 12V @ up to 700 mA (supervised); AUX total up to 700 mA shared

• Security/Radio: 128-bit AES, PowerG (approx. 912.75–919.106 MHz)

• Dimensions: ~8.9″ × 10″ × 3″ (enclosure)

• Operating range: 14–131°F (-10–55°C); 5–93% RH (non-condensing)

Upgrade & Expansion Module (PG9HRDW8)

• Adds CORBUS for compatible modules (e.g., zone expanders HSM2108, power supply, keypads)

• Enclosure: ~11.9″ × 15.6″ × 3.6″ metal cabinet

• Same electrical ratings/limits as above; UL/ULC listing applies to PG9HRDW8 with compatible IQ panels

• Panel compatibility noted: IQ Panel 2+ (v2.7.0+) and IQ4 (v4.1+) firmware baselines

Compatibility Notes

• Works with PowerG-equipped IQ Panels (IQ Panel 2+, IQ Panel 4, and compatible IQ Hub/IQ4 Hub firmware). Follow firmware requirements in the quick guide.

• Life-safety wiring: Use AUX2 for smoke/heat/CO devices; PGM2 is used for the 2-wire smoke loop.

• UL/ULC: Listing applies to PG9HRDW8 when used with listed IQ Panel combinations; follow the manual’s standby-time and current-draw limits.

Popular Use Cases

• Taking over a legacy wired alarm and migrating it to an IQ Panel

• Reusing wired motions, glass breaks, and contacts—plus adding automations via PGMs

• Adding a supervised 2-wire smoke loop (and/or wiring 4-wire smoke/heat/CO per manual)

Frequently Asked Questions

How many zones can I bring over?

Each module has 8 wired zones on-board; on supported setups you can expand to 24 with zone expanders.

Can it power my wired motions and glass breaks?

Yes. The converter provides 12V auxiliary power (shared budget); we size your loads and wiring to stay within limits.

Does it support 2-wire smoke detectors?

Yes—use PGM2 for a 2-wire smoke loop (up to 18 detectors). The manual also covers wiring 4-wire smoke/heat/CO devices.

What about sirens and strobes?

There’s a supervised 12V bell/siren output (up to ~700 mA), and PGMs can be used to drive relays or trigger devices.

Will this work with my IQ Panel?

It’s designed for PowerG-compatible IQ Panels. We verify firmware (e.g., IQ2+ 2.7.0+, IQ4 4.1.x+) and signal strength during installation.

Ready for a Clean Hardwired Takeover?

Smart Shield Systems will design the takeover plan, install and program your IQ Hardwire PowerG, label and test every zone, and set up the right automations—so your legacy wiring feels brand new.
